| Dimensions |
- 5.7 in. H x 3.4 in. W x 3.3 in. D
- 14.5 cm. H x 8.6 cm. W x 8.3 cm. D
|
| Weight |
11.2 oz. / 318.0 g |
| Input Voltage Range |
- 4.5 to 5.5Â VDC host powered; 4.5 to 5.5 VDC
- external power supply
|
- Operating Current at
- Nominal Voltage (5.0V)
|
Presentation mode: 335mA Trigger mode: 350mA |
| Standby Current (Idle) at Nominal Voltage (5.0V) |
Presentation mode: 135mA Trigger mode: 75mA |
| Color |
Alpine White, Midnight Black |
- Supported Host
- Interfaces
|
- USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX
- over RS485
|
| Keyboard Support |
Supports over 90 international keyboards |
- Electronic Article
- Surveillance
|
- Compatible with Checkpoint EAS
- deactivation system
|
| User Indicators |
- Good decode LEDs, rear view LEDs, beeper (Adjustable tone and volume)
|
| Swipe Speed (Presentation) |
Up to 120 in./305 cm. per second for 13 mil UPC in optimized mode |
| Light Source |
Aiming pattern: circular 617 nm amber LED |
| Illumination |
660 nm Hyper Red LED |
| Imager Field of View |
52° H x 33° V nominal |
| Image Sensor |
1280 x 800 pixels |
| Minimum Print Contrast |
15% |
| Skew Tolerance |
+/-60° |
| Pitch Tolerance |
+/-60° |
| Roll Tolerance |
360° |
| Operating Temperature |
32.0° F to 122.0° F / 0.0° C to 50.0° C |
| Storage Temperature |
-40.0° F to 158.0° F / -40.0° C to 70.0° C |
| Humidity |
5% to 95% RH, non-condensing |
| Drop Specification |
Designed to withstand multiple drops at 5.0 ft. / 1.5 m to concrete |
| Tumble Specification |
Designed to withstand 1,000 tumbles in 1.5 ft. /0.5 m tumbler |
| Environmental Sealing |
IP52 |
| Electrostatic Discharge (ESD) |
ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV indirect |
| Ambient Light Immunity |
0 to 10,000 foot-candles/0 to 107,700 Lux |
