Product Type |
Industrial Printer |
Print Method |
Thermal transfer and direct thermal printing |
Body Material |
Metal frame and bi-fold metal media cover |
Sensors |
Dual media sensors: transmissive and reflective |
Memory |
1 GB RAM memory, 2 GB on-board linear Flash memory |
Resolution |
203 dpi/8 dots per mm, 300 dpi/12 dots per mm (optional),600 dpi/24 dots per mm (optional for ZT610 only) |
Print Speed |
14 ips/356 mm per second |
Print Width |
4.09″/104 mm |
Media Type |
Continuous, die-cut, notch, black-mark |
Media Size |
8.0″/203 mm O.D. on a 3″/76 mm I.D. core |
Media Thickness |
0.0023″/0.058 mm to 0.010″/0.25 mm |
Ribbon Features |
(Thermal-transfer option only) Standard Length : 1476’/450 m , Width : 2.00″/51 mm to 4.33″/110 mm, Core : 1.0″/25.4 mm I.D. |
RFID Features |
Supports tags compatible with: UHF EPC Gen 2 V2, ISO/IEC 18000-63 and RAIN RFID protocols , Integrated RFID system is user-upgradable in the field and available on both 4″ and 6″ models , Adaptive Encoding Technology automatically selects optimum encode s |
Barcode Sets |
Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC, Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digitextensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MS |
Interface |
USB 2.0, high-speed, RS-232 Serial, Gigabit Ethernet,Bluetooth 4.0 |
Voltage |
Auto-detectable (PFC Compliant) 90-265 VAC, 47-63Hz |
Power Consumption |
Rated at 250 Watts |
Environment |
Operating Temperature: Thermal transfer = 40ºF to 104ºF/5ºC to 40ºC, Direct thermal = 32ºF to 104ºF/0ºC to 40ºC ; Operating Humidity: 20% to 85% non-condensing, Storage/Transportation Temperature: -22F to 140F/-30C to 60C,Storage Humidity: 20% to 85% no |
Certification |
IEC 60950, EN 55022 Class B, EN 55024, EN 61000-3-2,EN 61000-3-3, cTUVus, CE Marking, FCC-B, ICES-003, VCCI, C-Tick, NOM,S-Mark (Arg), CCC, CU, BSMI, KCC, SABS, IN-Metro |
Dimension |
(LxWxH) 19.88×10.56×15.58 Inch |
Weight |
50 lbs/22.7 kg |
